Metal

Invar 36

UNS K93600 | 1.3912 | FeNi36

ProcessCNC Machining

Need this material for your project?

Upload your drawing and get manufacturing support from our engineering team.

* Property values are for reference and may vary by alloy, temper, and processing conditions.

Invar 36 is an iron-nickel alloy with an extremely low thermal expansion coefficient and relatively low thermal conductivity. This confers exceptional dimensional stability, enabling it to remain distortion-free at specific temperatures. It is highly suitable for manufacturing high-precision components and can be used in environments sensitive to temperature fluctuations.

Material Properties

Mechanical Properties

Yield strength
275 - 310 MPa
Tensile strength
450 - 500 MPa
Elongation
30–40%
Hardness
150 - 180 HB
Young's modulus
141 - 145 GPa

Thermal properties

Maximum operating temperature
200 - 250°C
Thermal conductivity
10.5 - 11.5 W/m·K（20°C）
Coefficient of thermal expansion
1.3 - 1.8 μm/m·K（20-100°C）

Physical Properties

Density
8.10 g/cm³

Electrical properties

Electrical resistivity
0.80 - 0.85 μΩ·m（20°C）

Manufacturability

Manufacturability-Corrosion resistance
Poor to Medium
Manufacturability-Weldability
Moderate to Good
