Metal

Carbon Steel 1010

AISI 1010 | 1.0301 | C10

ProcessCNC Machining

Need this material for your project?

Upload your drawing and get manufacturing support from our engineering team.

* Property values are for reference and may vary by alloy, temper, and processing conditions.

Carbon Steel 1010 is a low-carbon steel, one of the most cost-effective and widely used common carbon steels. It exhibits excellent ductility and toughness, making it suitable for processes such as stamping, drawing, and bending. The material has good weldability but average machinability, with a tendency to stick to cutting tools during machining.

Material Properties

Mechanical Properties

Yield strength
180 - 230 MPa
Tensile strength
310–380 MPa
Elongation
25–35%
Hardness
95 - 120 HB
Young's modulus
190 - 210 GPa

Thermal properties

Maximum operating temperature
400 - 450°C
Thermal conductivity
49.8 - 51.9 W/m·K（20°C）
Coefficient of thermal expansion
11.5 - 12.5 μm/m·K（20-100°C）

Physical Properties

Density
7.87 g/cm³

Electrical properties

Electrical resistivity
~0.12 μΩ·m (20°C)

Manufacturability

Manufacturability-Corrosion resistance
Poor
Manufacturability-Weldability
Excellent
